| General specifications | LAN ports | Standard | IEEE 802.3 (10BASE-T/100BASE-TX/1000BASE-T) |
|---|---|---|---|
| Number of ports | 10 | ||
| Communication mode | Auto negotiation | ||
| Connector type | RJ-45 | ||
| MAC address | Printed on top surface label | ||
| Polarity | Automatic detection of straight/cross, or fixed at straight | ||
| Combo ports | LAN ports | IEEE 802.3 (1000BASE-T) 2 ports (use is mutually exclusive with SPF ports) | |
| SFP ports | SFP (Small Form-factor Pluggable) 2 ports (use is mutually exclusive with LAN ports) | ||
| SFP ports | Standard | IEEE 802.3z (1000BASE-SX/ 1000BASE-LX) | |
| Number of ports | 2 | ||
| Console ports | Standard | RS-232C, USB 2.0 | |
| Connector type | RS-232C, USB 2.0 | ||
| Data transmission speed | 9600 bit/s | ||
| Console port | RJ-45(RS-232C), USB mini-B(5pin)(USB2.0): 9600 bit/s | ||
| Ports available for PoE power supply | 8 ports (1-8) | ||
| PoE standards | IEEE 802.3at | ||
| Power supply system | Alternative A | ||
| Maximum power supply | Per port | 30 W | |
| All ports | 240 W | ||
| microSD slot | Standard | microSD/microSDHC (microSDXC is not supported) | |
| File System | FAT/FAT32 | ||
| Number of slots | 1 slot | ||
| Indicators | POWER, microSD, LAN port (LINK/ACT, SPEED), SFP port (LINK/ACT, SPEED) | ||
| MAC address | Indicated in product label on top panel of unit | ||
| Operating environment | Ambient temperature: 0–40 °C, Ambient humidity: 15–80%, non-condensing | ||
| Storage environment | Ambient temperature: -20–50 °C, Ambient humidity: 10–90%, non-condensing | ||
| Power supply voltage, frequency | AC100 ～ 240V, 50/60Hz | ||
| Maximum power consumption | 280 W | ||
| Dimensions | W | 220 mm | |
| H | 294 mm | ||
| D | 42.4 mm | ||
| Weight | 2.3 kg | ||
| Accessories | Owner’s manual, power cord, power cord clamp, rubber feet | ||
