Remotely control and monitor entire systems from a single panel
ProVisionaire Control and ProVisionaire Touch are software applications that provide unified remote control and monitoring of the entire systems. ProVisionaire Control supports Windows devices, and ProVisionaire Touch supports the iPad. A broad range of devices are supported, including MTX/MRX processors, CL/QL/TF digital mixers, Rio I/O units, XMV power amplifiers, and NEXO NXAMPMK2 powered TD controllers. Custom control panels can be created by assigning necessary parameters to a single display page. ProVisionaire Control includes the ProVisionaire Monitoring Service, making it easy to monitor the status of system devices while alerts and other log data can be recorded to a computer.
3 Key Features
Total System Control
Remotely control entire systems from a single panel
ProVisionaire can remotely control a wide range of Yamaha and Nexo equipments, including MTX/MRX series signal processors, CL/QL/TF series digital mixers, Rio series I/O boxes, XMV series power amplifiers, and Nexo NXAMPMK2 Powered TD Controllers from a single panel. With "External Event" function which is available in MTX/MRX series, even other companies devices such as projectors, curtains, and lights can be controlled. The system designer can specify which parameters from the available selection of products are to be included in the ProVisionaire designing, thus can create a fully customized control surface for the client. The ProVisionaire is a total control solution for the entire system.
Devices that Support Controlling
*There are models that are not available in some regions.
**Only ProVisionaire Touch Kiosk supports RM series. To control RM series with ProVisionaire Touch Kiosk, please design the controller screen using ProVisionaire Control and send it to ProVisionaire Touch Kiosk via Wi-Fi.
Control external devices including other companies' devices
With "External Events" function which is available in Yamaha processors MTX3, MTX5-D, and MRX7-D, you can issue UDP or TCP commands from the processors. This function makes it possible to control external devices including other companies' devices by Yamaha control devices such as ProVisionaire Control/Touch, Digital Control Panel, MCP1 and Wireless DCP. For example, you can turn on the projector, close the curtain, turn off the lights, by recalling presets.
Dante network for AV presentation/ BGM/ Paging system (Enterprise/ Education/ Hotel Banquet)
- Aggregate in-house broadcasting and voice control for multiple areas in a MRX7-D system, all managed with ProVisionaire Control.
- Digital mixer for situations in which additional voice inputs and detailed operation are required for panel discussions, lectures, band performances, etc.
- A single operator can monitor the CL5, QL5 and Rio3224-D2 from one computer running ProVisionaire Control.
Comprehensive control both audio and video content (Conference rooms, Auditrium, Multipurpose halls, Hotel Banquet)
- Microphones, a Blu-ray player, computer playback, and video switching can all be controlled from the Provisionaire Control or ProVisionaire Touch.
- Utilize MTX5-D Dugan Automatic mixing function when more voice input is required for panel discussion and lecture. It can manage the level of each microphone, achieving better clarity in sound and suppressing unwanted feedback.
Remote MusicCast® control makes the most of music content (Available in ProVisionaire Touch)
Remote volume, playback, and audio device control
Remote control of MusicCast enabled audio devices is supported. A MusicCast capable wireless straming amplifiers such as the WXC-50 could be added to an installation that is based on MTX and/or MRX series processors, with playback and track selection controlled via a WiFi network from a single iPad. This type of capability is ideal for controlling playback devices, adjusting volume, and selecting areas in restaurant and banquet hall situations.
Video content support
By combining MTX/MRX system with the MusicCast® compatible AV receiver, it is possible to select the music source, switch the HDMI input source with the AV receiver, and control the devices all together with one iPad. For example, by combining video and audio content control in one iPad used in a conference room or classroom, a simpler and more convenient control system can be constructed.
Disklavier™ ENSPIRE control support (Available in ProVisionaire Touch)
Remote entertainment control from playback to performance
ProVisionaire Touch supports the Yamaha Disklavier™ ENSPIRE, providing wireless remote control of automated acoustic piano playback as well as DisklavierRadio streaming. Centralized control of BGM sources such as WXC-50 as well as the Disklavier from the ProVisionaire Touch app makes it easy to switch between acoustic piano and recorded sources according to the time of day or event schedules. ProVisionaire Touch is a smooth, effortless way to remotely control a variety of entertainment programs.
ProVisionaire Monitoring Service (Available in ProVisionaire Control)
In a theater situation where multiple devices with monitoring capability such as digital mixers, I/O racks, and power amplifiers are distributed throughout the area, a single operator can monitor and manage the entire system from one computer. Not only can faults that aren’t visible from the device’s exterior be easily and quickly detected, but the log makes it easy to identify precisely where problems originate from. ProVisionaire Control is an excellent tool for keeping track of device connection status as well as preventing, detecting, and solving problems. The addition of improved audio system monitoring capability will notable increase system convenience and reliability.
Devices that Support System Monitoring
|Signal Processor||MTX3, MTX5-D, MRX7-D|
|Digital Mixing Console, Digital Mixer||QL1, QL5|
|CL1, CL3, CL5|
|CS-R3, CS-R5, CSD-R7, CS-R10S, CS-R10|
|Power Amplifier||XMV4140, XMV4140-D, XMV4280, XMV4280-D, XMV8140, XMV8140-D, XMV8280, XMV8280-D|
|PC406-D, PC406-DI, PC412-D, PC412-DI|
|NEXO Powered TD Controller||NXAMP4x1 MK2, NXAMP4x2 MK2, NXAMP4x4 MK2|
Custom Control Panel
Customizable control panel software
By simply dragging and dropping widgets such as faders and switches in a graphic interface from ProVisionaire widgets or MTX-MRX Editor, you can create custom control panels dedicated to the applications and functions required for any installation. No programming know-how or experience is necessary. Yamaha provides a versatile range of remote-control options to suit various installation types and user requirements, ranging from simple remotes to fully customizable software-based control for Windows devices or iPad.
You can find good-looking various templates in the download page. By simply adjusting the number of mics and any kind of buttons, you can easily create a good-looking controller design for many types of application that will be welcomed by the customers. We also have various types of icons that will be useful for customization.
Security Built In
User Level Access Control
ProVisionaire Touch and Control have four user level management functions. By utilizing this function, it prevents controller users from accessing the operating system so that unintended control or design changes cannot occur.
|Unlock the screen lock||-||-||-|
|Edit a controller file||-||-|
|Edit the design||-||-||-|
ProVisionaire Control/Touch KIOSK
ProVisionaire Control KIOSK and ProVisionaire Touch KIOSK allows the Windows devices or iPad to be set up to function as a dedicated controller, preventing users from accessing the operating system or other applications so that unintended control or design changes cannot occur. The use of ProVisionaire Control KIOSK or Touch KIOSK will provide smooth and safe operation.
|ProVisionaire Control||ProVisionaire Control KIOSK||ProVisionaire Touch||ProVisionaire Touch KIOSK|
Use ProVisionaire Control to design ProVisionaire Touch KIOSK
Controller screen for "ProVisionaire Touch KIOSK" iPad application can be designed using "ProVisionaire Control" Windows software and sent directly via Wi-Fi. The controller design interoperability this provides is advantageous when you need to efficiently create large numbers of controllers.
The colors and finishes shown may vary from those on the actual products.
