PSR-SX920 New

PSR-SX920 PSR-SX720 PSR-SX600
Body Color Black Black Black
Dimensions Width 1,017 mm (40") 1,017 mm (40") 1004 mm
Height 139 mm (5-1/2") 139 mm (5-1/2") 134 mm
Depth 431 mm (17") 431 mm (17") 410 mm
Weight Weight 11.6 kg (25.57 lbs.) 11.6 kg (25.57 lbs.) 8.1 kg
Packing Box Width 1,174 mm (46-3/16") 1,174 mm (46-3/16") 1,110 mm (43-11/16")
Height 246 mm (9-11/16") 246 mm (9-11/16") 231 mm (9-1/8")
Depth 511 mm (20-1/8") 511 mm (20-1/8") 528 mm (20-13/16")
Keyboard Number of Keys 61 61 61
Type Organ (FSB), Initial Touch Organ (FSB), Initial Touch Organ, Initial Touch
Touch Response Normal, Soft1, Soft2, Hard1, Hard2 Normal, Soft1, Soft2, Hard1, Hard2 Normal, Soft 1, Soft 2, Hard 1, Hard 2
Other Controllers Joystick Yes (Assignable) Yes (Assignable) -
Control Knobs 2 (Assignable) 2 (Assignable) 2 (assignable)
Assignable Buttons 6 + 2 (With LED Indicator) 6 + 2 (With LED Indicator) -
Pitch Bend - - Yes
Modulation - - Yes
Display Type TFT Color Wide VGA LCD TFT Color Wide VGA LCD TFT Color WQVGA LCD
Size 800 x 480 dots (7 inch) 800 x 480 dots (7 inch) 480 x 272 dots (4.3 inch)
Touch Screen Yes Yes -
Color Yes Yes Color
Language English, German, French, Spanish, Italian, Chinese English, German, French, Spanish, Italian, Chinese English, German, French, Spanish, Italian, Japanese
Panel Language English, Chinese English, Chinese English
Tone Generation Tone Generating Technology AWM Stereo Sampling, AEM technology AWM Stereo Sampling AWM Stereo Sampling
Polyphony Number of Polyphony (Max.) 128 128 128
Preset Number of Voices 1,587 Voices + 63 Drum/SFX Kits + 480 XG Voices 1,377 Voices + 56 Drum/SFX Kits + 480 XG Voices 850 Voices + 43 Drum/SFX Kits + 480 XG Voices
Featured Voices 12 S.Articulation2, 15 S.Articulation+, 340 S.Articulation, 55 OrganFlutes, 82 MegaVoice 9 S.Articulation+, 252 S.Articulation, 55 OrganFlutes, 54 MegaVoice 73 S.Articulation!, 27 MegaVoice, 27 Sweet!, 64 Cool!, 71 Live!
Expandability Expansion Voice Yes (approx. 2 GB) Yes (approx. 1 GB) Yes (approx. 100MB max.)
Editing - - Voice Set
Compatibility XG, GM, GM2 (for Song Playback) XG, GM, GM2 (for Song Playback) -
XG - - Yes (for Song playback)
GS - - Yes (for Song playback)
GM - - Yes
GM2 - - Yes
Part Right1, Right2, Right3, Left Right1, Right2, Right3, Left Right 1, Right 2, Left
Types Reverb 59 Preset + 30 User 59 Preset + 30 User 52 Preset + 30 User
Chorus 107 Preset + 30 User 106 Preset + 30 User 106 Preset + 30 User
DSP 358 Preset (with VCM) + 30 User 322 Preset + 30 User 295 Preset + 30 User
Insertion Effect 1-13: 358 Preset (with VCM) + 30 User 1-8: 322 Preset + 30 User -
Master Compressor 5 Preset + 30 User 5 Preset + 30 User 5 Preset + 30 User
Master EQ 5 Preset + 30 User 5 Preset + 30 User 5 Preset + 30 User
Part EQ 28 Parts 28 Parts 27 Parts
Others - - Mic effects: Noise Gate x 1, Compressor x 1, 3 Band EQ
Arpeggio - - Yes
Vocal Harmony Number of Presets Vocal Harmony: 54, Synth Vocoder: 20 - -
Number of User Settings 60 *The number is the total of Vocal Harmony and Synth Vocoder - -
Preset Number of Preset Styles 575 450 415
Featured Styles 520 Pro Styles, 49 Session Styles, 6 Free Play Styles 410 Pro Styles, 37 Session Styles, 3 Free Play Styles 372 Pro Styles, 32 Session Styles, 10 DJ Styles, 1 Free Play
Fingering Single, Fingered, OnBass, Multi, AI Fingered, Full / AI Full, Smart Chord Single, Fingered, OnBass, Multi, AI Fingered, Full / AI Full, Smart Chord Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard, Smart Chord
Style Control INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3 INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3 INTRO x 3, MAIN VARIATION x 4, FILL x 4, BREAK, ENDING x 3
Compatibility Style File Format, Style File Format GE Style File Format, Style File Format GE Style File Format (SFF), Style File Format GE (SFF GE)
Expandability Expansion Style Yes (Internal Memory) Yes (Internal Memory) Yes (Internal Memory)
Expansion Audio Style Yes (Internal Memory) - -
Other Features Chord Looper Yes Yes -
Style Section Reset Yes Yes Yes
Style Section Change Timing Yes Yes -
Style Section Time Signature Yes (per Section) Yes (per Section) -
Style Dynamics Control Yes (with knobs / pedal) Yes (with knobs / pedal) -
One Touch Setting (OTS) 4 for each Style 4 for each Style 4 for each Style
Unison & Accent - - Yes
Preset Number of Preset Songs 1 Demo Song, 2 Preset Songs 1 Demo Song, 2 Preset Songs 3 Sample Songs
Recording Number of Songs Unlimited (depending on USB flash memory capacity) Unlimited (depending on USB flash memory capacity) -
Number of Tracks 16 16 16
Data Capacity Approx. 3 MB/Song Approx. 3 MB/Song Approx. 1 MB/Song
Recording Function Quick Recording, Multi Recording, Step Recording Quick Recording, Multi Recording, Step Recording Quick Recording, Multi Track Recording
Compatible Data Format Playback SMF (Format 0 & 1), XF SMF (Format 0 & 1), XF SMF (Format 0 & 1), XF
Recording SMF (Format 0) SMF (Format 0) SMF (Format 0)
Preset Number of Multi Pad Banks 500 banks x 4 Pads 349 banks x 4 Pads 188 Banks x 4 Pads
Audio Audio Link Yes Yes Yes
Voices Harmony/Echo Yes (with Arpeggio) Yes (with Arpeggio) Yes (with Arpeggio)
Panel Sustain Yes Yes Yes
Mono/Poly Yes (w/ Legato, Xfd (improved), VeloToPrtTime, FastPlayingPortamento, Velocity Limit) Yes (w/ Legato, Xfd (improved), VeloToPrtTime, FastPlayingPortamento, Velocity Limit) Yes
Voice Information Yes Yes Yes
Styles Style Creator Yes Yes Yes
OTS Information Yes Yes Yes
Songs Song Creator Yes Yes Yes
Score Display Function Yes Yes Yes
Lyrics Display Function Yes Yes Yes
Multi Pads Multi Pad Creator Yes Yes Yes
Registration Number of Buttons 8 8 8
Control Registration Sequence, Freeze Registration Sequence, Freeze Registration Sequence, Freeze
Playlist Number of Records 2,500 (max.) Records per Playlist file (add search/sort function improved) 2,500 (max.) Records per Playlist file (add search/sort function improved) 500 (max.) Records per Playlist file
Search Registration Bank Registration Bank Registration Bank
Audio Recorder/Player Recording Time (max.) 80 minutes/Song 80 minutes/Song 80 minutes/Song
Recording .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (44.1 kHz sample rate,128/256/320 kbps, mono/stereo) .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (44.1 kHz sample rate,128/256/320 kbps, mono/stereo) *only on USB .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo)
Playback .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (MPEG-1 Audio Layer-3: 44.1/48.0 kHz sample rate, 64-320 kbps and variable bit rate, mono/stereo) .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo), .mp3 (MPEG-1 Audio Layer-3: 44.1/48.0 kHz sample rate, 64-320 kbps and variable bit rate, mono/stereo) *only on USB .wav (WAV format: 44.1 kHz sample rate, 16 bit resolution, stereo)
Time Stretch Yes Yes Yes
Pitch Shift Yes Yes Yes
Vocal Cancel Yes Yes Yes
Lyrics Display Function - - -
Demo/Help Demonstration Yes Yes Yes
Overall Controls Metronome Yes Yes Yes
Tempo Range 5 - 500, Tap Tempo 5 - 500, Tap Tempo 5 - 500, Tap Tempo
Transpose -12 – 0 – +12 -12 – 0 – +12 -12 – 0 – +12
Tuning 414.8 – 440 – 466.8 Hz 414.8 – 440 – 466.8 Hz 414.8 – 440.0 – 466.8 Hz
Octave Button -3 -0- 3 -3 -0- 3 Yes
Scale Type 9 Preset 9 Preset 9 types
Sub Scale Setting Yes Yes -
Miscellaneous Direct Access Yes Yes Yes
Text Display Function Yes Yes Yes
Wallpaper Customization Yes Yes -
Display Out Yes (via USB to DEVICE) - -
Bluetooth Yes (depends on destination) - -
Lesson/Guide Lesson/Guide - - Follow Lights, Any Key, Karao-Key, Your Tempo
Storage Internal Memory Approx. 4 GB max. Approx. 1 GB max. Yes (approx. 20 MB max.)
External Drives USB Flash Memory (via USB to DEVICE) USB Flash Memory (via USB to DEVICE) USB flash drive
Connectivity Headphones Yes Yes Yes
Microphone Mic/Guitar Mic/Guitar Microphone x 1
MIDI IN/OUT IN/OUT -
AUX IN Stereo mini Stereo mini Stereo mini jack
LINE OUT L/ L+R, R, Sub 1/2 L / L+R, R MAIN OUTPUT(L/L+R, R)
DIGITAL OUT - - -
FOOT PEDAL Assignable, Sw or Vol x2 Assignable, Sw or Vol x2 1 (Sustain), 2 (Unison), Function Assignable
USB TO DEVICE USB 2.0 ×2 USB 2.0 ×1 Yes
USB TO HOST USB 2.0 ×1 USB 2.0 ×1 Yes
Wireless LAN - - -
Amplifiers (15 W+10 W) x2 15 W x2 15 W x 2
Speakers [13 cm FSP+2.5 cm, (Dome type)] x2 [13 cm + 5 cm ] x2 12 cm x 2
Power Supply PA-300C or an equivalent recommended by Yamaha PA-300C or an equivalent recommended by Yamaha PA-300C or an equivalent recommended by Yamaha
Power Consumption 24 W 21 W 17 W
Auto Power Off Function Yes Yes Yes
Included Accessories Owner's Manual, Music Rest, AC Adaptor (may not be included depending on your area. Check with your Yamaha dealer.) Owner's Manual, Music Rest, AC Adaptor (may not be included depending on your area. Check with your Yamaha dealer.) Owner's Manual, Online Member Product Registration, Music Rest, AC Adaptor (may not be include depending on your area. Check with your Yamaha dealer.)
