YC Series - YC61, YC73 and YC88

Control Interface

Keyboard

Number of Keys

Type

Voices

Tone Generation

Tone Generating Technology

Polyphony

Number of Polyphony (Max.)

Number of Live Set Sound

Number of Voices

Effects

Types

Insertion Effect

Effect

Speaker/Amp

Reverb

Master EQ

Connectivity

Connectors

Line Out

Headphones

Foot Controller

MIDI

USB

AUX

Other

Connectors

Display

Additional package contents

Size/Weight

Dimensions

Width

Height

Depth

Weight

Packing Box

Width

Height

Depth

		YC61	YC73	YC88

		YC61	YC73	YC88
Control Interface
Keyboard	Number of Keys	61	73	88
Keyboard	Type	Semi-weighted Waterfall keyboard, initial touch	BHS (Balanced Hammer Standard) keyboard: matte black keytops	NW-GH3 (Natural Wood Graded Hammer) keyboard: synthetic ebony and ivory keytops
Voices
Tone Generation	Tone Generating Technology	VCM Organ, AWM2, FM	VCM Organ, AWM2, FM	VCM Organ, AWM2, FM
Polyphony	Number of Polyphony (Max.)	[VCM Organ + AWM2]:128 *Total of VCM Organ and AWM2, [FM]:128	[VCM Organ + AWM2]:128 *Total of VCM Organ and AWM2, [FM]:128	[VCM Organ + AWM2]:128 *Total of VCM Organ and AWM2, [FM]:128
Number of Live Set Sound		160 (Preset Live Set Sounds:144)	160 (Preset Live Set Sounds:144)	160 (Preset Live Set Sounds:144)
Number of Voices		191 (Organ:10 / Keys:181)	191 (Organ:10 / Keys:181)	191 (Organ:10 / Keys:181)
Effects
Types	Insertion Effect	Organ 1 systems (Pre Drive) / Key A 2 systems (1: 35 types, 2: 35 types) / Key B 2 systems (1: 35 types, 2: 35 types)	Organ 1 systems (Pre Drive) / Key A 2 systems (1: 35 types, 2: 35 types) / Key B 2 systems (1: 35 types, 2: 35 types)	Organ 1 systems (Pre Drive) / Key A 2 systems (1: 35 types, 2: 35 types) / Key B 2 systems (1: 35 types, 2: 35 types)
	Effect	35 types	35 types	35 types
	Speaker/Amp	7 types (Rotary Speaker: 3 types, Amp: 4 types)	7 types (Rotary Speaker: 3 types, Amp: 4 types)	7 types (Rotary Speaker: 3 types, Amp: 4 types)
	Reverb	1 type	1 type	1 type
	Master EQ	3 band (with sweepable Mid)	3 band (with sweepable Mid)	3 band (with sweepable Mid)
Connectivity
Connectors	Line Out	OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks, UNBALANCED)	OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks, UNBALANCED), OUTPUT [L]/[R] (XLR jacks, BALANCED)	OUTPUT [L/MONO]/[R] (6.3 mm, standard phone jacks, UNBALANCED), OUTPUT [L]/[R] (XLR jacks, BALANCED)
	Headphones	[PHONES] (6.3 mm, standard stereo phone jack)	[PHONES] (6.3 mm, standard stereo phone jack)	[PHONES] (6.3 mm, standard stereo phone jack)
	Foot Controller	FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE]	FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE]	FOOT CONTROLLER [1]/[2], FOOT SWITCH [SUSTAIN]/[ASSIGNABLE]
	MIDI	MIDI [IN]/[OUT]	MIDI [IN]/[OUT]	MIDI [IN]/[OUT]
	USB	USB [TO HOST]/[TO DEVICE]	USB [TO HOST]/[TO DEVICE]	USB [TO HOST]/[TO DEVICE]
	AUX	INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks)	INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks)	INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks)
Other
Connectors		[AC IN]	[AC IN]	[AC IN]
Display		Full Dot LCD (128 x 64 dots)	Full Dot LCD (128 x 64 dots)	Full Dot LCD (128 x 64 dots)
Additional package contents		Owner’s Manual x 1, Power cord x 1	Owner’s Manual x 1, Power cord x 1, Foot pedal (FC3A) x 1	Owner’s Manual x 1, Power cord x 1, Foot pedal (FC3A) x 1
Size/Weight
Dimensions	Width	896 mm (35-1/4")	1086 mm (42-3/4")	1298 mm (51-1/8")
	Height	108 mm (4-1/4")	145 mm (5-11/16")	142 mm (5-9/16")
	Depth	309 mm (12-3/16")	355 mm (14")	364 mm (14-5/16")
Weight	Weight	7.1 kg (15 lb, 10 oz)	13.4 kg (29 lb, 9 oz)	18.6 kg (41 lb, 0 oz)
Packing Box	Width	1,035 mm (40-3/4")	1,358 mm (53-7/16")	1,548 mm (60-15/16")
	Height	240 mm (9-7/16")	291 mm (11-7/16")	291 mm (11-7/16")
	Depth	444 mm (17-1/2")	524 mm (20-5/8")	524 mm (20-5/8")
